Body material Magnesium alloy
Sensor • 23.7 x 15.7 mm CMOS sensor
• DX format
• RGB Color Filter Array
• Built-in fixed low-pass filter
• 12.84 million total pixels
• 12.4 million effective pixels
• 5.49 x 5.49 µm
• 3:2 aspect ratio
Image sizes
(Full image)		 • 4288 x 2848 [L]
• 3216 x 2136 [M]
• 2144 x 1424 [S]
Image sizes
(High speed
cropped)		 • 3216 x 2136 [L]
• 2400 x 1600 [M]
• 1600 x 1064 [S]
File formats • NEF (12-bit RAW)
• NEF + JPEG
• JPEG (EXIF 2.2)
• TIFF (RGB)
Color space • sRGB (2 modes)
• Adobe RGB (2 modes)
• sYCC
Lens mount • Nikon F mount
• Full size image: 1.5x field of view crop
• High speed cropped: 2.0x field of view crop
Usable lenses • AF Nikkor (including AF-S, DX, VR and D-/G-type) : All functions possible
• D-type Manual-Focus Nikkor: All functions except autofocus and some
exposure modes available
• AF Nikkor other than D-/G-type: All functions except 3D Color Matrix
Metering and 3D Multi-Sensor Balanced Fill-Flash possible
• AI-P Nikkor: All functions except 3D Color Matrix Metering,
3D Multi-Sensor Balanced Fill-Flash and AF possible
• Non-CPU AI Nikkor : Usable in [A] or [M] mode with Matrix-Metering,
Center-Weighted and Spot metering available. Indication of aperture No.,
after user inputs the aperture f/No. and focal length f=mm by multi-selector
operation.
* Electronic Rangefinder usable with maximum aperture of f/5.6 or faster
Auto Focus • 11 area TTL (9 area when in High speed cropped mode)
• Multi-CAM2000
• AF working range: -1 to 19 EV (ISO 100, normal temperature)
Lens Servo • Single Servo AF [S]
• Continuous Servo AF [C]
• Manual focus [M]
* Focus Tracking automatically activated by subject’s status in [S] or [C] AF
AF Area Mode • Single Area AF
• Dynamic AF with Focus Tracking and Lock-on
• Closest Subject Priority Dynamic AF
• Group Dynamic AF
AF assist None (via. external flash)
AF Lock • Locked using the AE-L/AF-L button
• Half-press shutter release button in AF mode [S]
Exposure modes • Program Auto [P] – flexible program possible
• Shutter-Priority Auto [S]
• Aperture-Priority Auto [A]
• Manual [M]
Metering TTL full-aperture exposure metering system;
• D-/G-type Nikkor lenses support 3D Color Matrix Metering II using the 1,005-pixel CCD while other AF Nikkor lenses with built-in CPUs support Matrix Metering (Non-CPU lenses require manual input of lens data)
• Center-Weighted Metering (75% of the meter’s sensitivity concentrated on the 8mm dia. circle)
• Spot Metering (3mm dia. circle, approx. 2% of entire frame); metering position can be linked to the focus area when using Nikkor lenses with built-in CPU
Metering modes • 3D Color Matrix
• Center-Weighted
• Spot
Metering range • 3D Color Matrix Metering: EV 0 to 20
• Center-Weighted Metering: EV 0 to 20
• Spot Metering: EV 2 to 20
[at normal temperature (20°C/68°F), ISO 100 equivalent, f/1.4 lens]
Meter Coupling CPU and AI (Automatic maximum aperture indexing)
AE Lock Locked using AE-L/AF-L button
AE Bracketing • 2 to 9 frames
• 1/3, 2/3 or 1 EV steps
Exposure compen. • +/-5.0 EV
• 1/3, 1/2 or 1.0 EV steps
Sensitivity • ISO 100 – 800
• 1/3, 1/2 or 1.0 EV steps
Shutter • Electromagnetically controlled vertical-travel Focal-plane shutter
• 30 to 1/8000 sec
• Flash X-Sync: 1/250 sec
• Bulb
White balance • Auto (hybrid: ambient sensor, 1005-pixel CCD, image sensor)
• Presets (five)
• Manual (six steps with fine tuning)
• Color temperature in Kelvin (31 steps)
• White balance bracketing (2 to 9 frames, 10,20,30 MIRED steps)
Image parameters • Sharpening: Auto, Normal, Low, Medium Low, Medium High, High, None
• Tone: Auto, Normal, Less Contrast, More Contrast, Custom
• Color: -3,-2,-1,0,+1,+2,+3
• Hue: +/-3, +/-6, +/-9 degrees
Viewfinder • Optical-type fixed eye-level pentaprism
• Built-in diopter adjustment (-3 to +1m-1)
• Eyepiece shutter provided
• Eyepoint: 19.9 mm (at -1.0m-1)
• Frame coverage 100%
• Viewfinder magnification approx 0.86x with 50 mm f/1.4 lens
Focusing screen • B-type BrightView Clear Matte Screen III and V-Type Screen for High speed cropped
• Interchangeable with optional E-type finder screen with grid
Viewfinder info • Focus indications
• Shutter speed
• Aperture
• Exposure mode
• Metering system
• Shutter speed lock
• Aperture lock
• AE lock
• Bracketing indicator
• Electronic analogue display
• Frame counter
• Ready-light
• ISO sensitivity
• White balance
• Image size / quality
• Eleven sets of focus brackets (area)
• High speed cropped area
LCD monitor • 2.5 ” TFT LCD
• Tempered glass coating
• 235,000 pixels
• Backlight / brightness adjustment
Flash control • New Creative Lighting System: i-TTL Balanced Fill-Flash controlled by five-segment TTL Multi Sensor with Nikon Speedlight SB-800/600: Advanced Wireless Lighting, FV (Flash Value) -lock, Flash Color Information Communication for Auto White Balance, Auto FP High-Speed Flash Sync, Modeling Flash
• D-TTL Balanced Fill-Flash: When used with the Speedlight SB-80DX/50DX and in accordance with the mounted lens, five-segment TTL Multi Sensor control makes available 3D Multi-Sensor Balanced Fill-Flash, Multi-Sensor Balanced Fill-Flash, and Standard D-TTL Balanced Fill-Flash
• AA (Auto Aperture)-type Flash available when used with SB-800/80DX and lens with built-in CPU
• Non-TTL Auto Flash (A-type Flash) with a Speedlight such as SB-30/27/22s etc.
• Range-priority manual available with SB-800
Flash Sync Mode • Front-Curtain Sync (normal sync)
• Red-Eye Reduction
• Red-Eye Reduction with Slow Sync
• Slow Sync
• Rear-Curtain Sync
Flash Ready-Light Lights up when flash fully charged with Speedlight SB-800/80DX/50DX/30/28/
27/22s; blinks for full output warning
Flash Accessory Shoe ISO 518 standard-type hot shoe contact; Safety lock mechanism provided
Flash Sync Terminal ISO 519 standard terminal, lock screw provided
DOF Preview • Stop-down lens aperture by pressing button
• Activates modelling flash
Shooting modes • Single
• Continuous High [CH] Full image – 5 fps
• Continuous High [CH] High speed cropped image – 8 fps
• Continuous Low [CL] Full image – 1 to 4 fps (custom)
• Continuous Low [CL] High speed cropped image – 1 to 7 fps (custom)
• Buffer size: Full image 15 NEF, High speed cropped image 26 NEF
• Self-Timer (programmable)
• Interval timer (Timelapse)
Self-timer • 2, 5, 10 or 20 sec programmable
Voice recording • Voice memo (up to 60 sec)
• Optional auto record
Orientation sensor Tags images with camera orientation
Playback mode • Full frame
• Thumbnail (4 or 9 images)
• One-touch zoom
• Slideshow
• Histogram
• Highlight point
Connectivity • USB 2.0 (Hi-Speed) Mini-B connector
• Video out
• Remote control 10-pin
• PC Sync flash terminal
GPS NMEA 0183 Interface standard supported with GPS Cable MC-35 (optional)
Communications FTP file transfer with optional Wireless Transmitter WT-1 (IEEE 802.11b) or WT-2 (IEEE 802.11b/g)
Video out • NTSC
• PAL
Storage • Compact Flash Type I or II
• Microdrive supported
• FAT 12/16 and FAT 32 support
• 30 characters of text can be input and stored in EXIF header
• No CF card supplied
Power • Lithium-Ion EN-EL4 (11.1 V DC)
• Included battery charger MH-21 (100 min full charge)
• Optional AC adapter EH-6
Battery monitoring The LCD monitor on the camera back displays the following information
about the EN-EL4 battery:
• Remaining charge (%)
• No. of shots taken since last charge
• Calibration status (Recommended/Not required)
• Battery life (5 stages)
Dimensions 158 x 150 x 86 mm (6.2 x 5.9 x 3.4 in)
Weight (no batt) 1070 g (2.4 lb)
Weight (inc. batt) 1252 g (2.8 lb)
Box contents Li-ion Battery EN-EL4, Quick Charger MH-21, Body Cap, Camera Strap AN-D2X, AV Cable EG-D2, USB Cable UC-E4, LCD Monitor Cover BM-3, PictureProject Software CD-ROM
Optional accessories Wireless Transmitter WT-1, Wireless Transmitter WT-2, Extension Antenna WA-E1, AC Adaptor EH-6, E-type Finder Screen, Anti-fog Finder Eyepiece DK-16A, Eyepiece Correction Lens DK-16C series, Speedlight SB-800/80DX/50DX, Nikon Capture 4 software, CompactFlash™ card
